Model No: NTW-12,NTW-24,Customizable
Tempat Asal: Cina
Status: Baru
Jenis Dari: Mesin Suhu Air
Inspeksi Pabrik Video: Disediakan
Laporan Uji Mekanis: Disediakan
Masa Garansi Komponen Inti: 1 tahun
Komponen Inti: Motor
Masa Garansi: 1 tahun
Nilai Jual Inti: Mudah Dioperasikan, Akurasi tinggi, Kontrol suhu yang akurat, Umur Panjang
Layanan Di Luar Garansi: Dukungan teknis video
Brand Name: Niasi
Voltage: AC380V/50Hz/3P
Controller: P.I.D microcomputer
Temperature Control Accuracy: ±0.1℃
Penggunaan: Plastic industry
| Menjual unit: | Bag/Bags |
|---|
The file is encrypted. Please fill in the following information to continue accessing it
| Model | NTW-06 | NTW-09 | NTW-12 | NTW-24 | NTW-06D | NTW-09D | NTW-12D | NTW-24D |
|---|---|---|---|---|---|---|---|---|
| Heater Power (KW) | 6 | 9 | 12 | 24 | 6*2 | 9*2 | 12*2 | 24*2 |
| Heat Transfer Medium | Water | Water | Water | Water | Water | Water | Water | Water |
| Cooling Mode | Direct Cooling | Direct Cooling | Direct Cooling | Direct Cooling | Direct Cooling | Direct Cooling | Direct Cooling | Direct Cooling |
| Water Pressure (kg/cm²) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 |
| Cooling Water Piping | PT1/2 | PT1/2 | PT1/2 | PT1/2 | PT1/2 | PT1/2 | PT1/2 | PT1/2 |
| Maximum Temperature (°C) | 120 | 120 | 120 | 120 | 180 | 180 | 180 | 180 |
| Temperature Accuracy (°C) | ±0.1 | ±0.1 | ±0.1 | ±0.1 | ±0.1 | ±0.1 | ±0.1 | ±0.1 |
| Pump Power (HP) | 0.5 | 1 | 1 | 2 | 0.5 | 1 | 1 | 2 |
| Pump Flow (L/min) | 35 | 45 | 45 | 70 | 35 | 45 | 45 | 70 |
| Pump Head (M) | 26 | 26 | 26 | 26 | 26 | 26 | 26 | 26 |
| System Power Supply | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ | AC 380V/3P/50HZ |
| External Dimensions (cm) | 51×52×23.5 | 62×59×29 | 67×70×29 | 67×79×35 | 51×52×23.5 | 62×59×29 | 67×70×29 | 67×79×35 |
| Weight (kg) | 40 | 50 | 55 | 65 | 40 | 50 | 55 | 65 |
